Hardware Features

Interface

1 RJ-45 for WAN port (Ethernet 100 Base-T)
1 RJ-45 for LAN port (Ethernet 100 Base-T)
1 RJ-11 for FXS port
IEEE802.11 b/g/n

Power Supply

AC Input : 100-240v, 50-60Hz;

Environmental

Operation Temperature: -5~45 Degree C
Storage Temperature: -25~85 Degree C
Relatively Humidity: 10%~90% No Condensing
Shock: Up to 75cm Drop upon package

Dimension

(L)85×(W)85×(H)28mm

Unit Weight

366g(without package)

Software Features

Audio Codec Features

G.711 (A-Law, u-Law) with PESQ above 4.3
G.729 with PESQ above 3.7
Adaptive Jitter Buffer Management
Voice Activity Detection
Comfort Noise Generation
Echo Cancellation
T.30 FAX with G.711
Real time FAX over IP via T.38

Protocols

SIP V2.0 (RFC 3261, 3262, 3263, 3264)
Backward compatible with RFC2543
Session timer (RFC4028)
SDP (RFC2327)
RTP/RTCP (RFC823/903)
NAPTR for SIP URI lookup (RFC2915)
STUN (RFC2030)
ARP/RARP (RFC 826/903)
SNTP (RFC 2030)
DHCP/PPPoE
HTTP Server for Web Management
TFTP/HTTP for Auto Provisioning
Message Waiting Indicator (RFC3842)
DHCP Option Codes for SIP (RFC3361)
DNS/DNS SRV (RFC1706 and RFC 2782)
IEEE802.1Q VLAN/802.1p and IP DSCP

Management

Firmware Upgrade
Web Management Interface
IVR-driven Management Interface
Local and Remote Syslog (RFC3164)
Auto Provisioning
SNTP Time Synchronization
Multi User Level
SNMP v2
Telnet
TR069
System Log: local log and remote log

Wireless

4 SSID per Radio
Static WEP(64/128bit)
Dynamic WEP(64/128bit)
AES(CCMP/TKIP)
MAC certification
WEP certification
WPA-PAK/WPA-PSK(2.0)
WPA/WPA2
AP Isolation and MBSSID AP Isolation
WMM
WDS
WPS
Station list
Radius certification and billing
MAC Filter(different from wired MAC Filter)

Applications

Support NAT mode and Bridge mode
Support DDNS
MAC address cloning
SIP proxy redundancy
NAT Traversal by STUN
Built-in Wired speed NAT Router
DHCP Server and Client
IP conflict detection
Port Forwarding, DMZ, SuperDMZ
802.1Q VLAN/802.1p, DSCP, Rate Limiting
VPN(PPTP,L2TP, IPSec) Passthrough
SNTP
IGMPv2,IGMPv3
ACL(Access Control List)
Broadcast Strom Control
Mac Filtering
Firewall(SYN Flooding, IP Spoofing, Smurf Attack, Ping of Death, DoS)
Ipv6(Dual Stack)
MLDv1, MLDv2

Call Features

3-way conference
Call hold
Call forwarding
Call Transfer
Call waiting
Caller ID and CWCID
DTMF Relay: In-band, Out-band and SIP INFO
QoS Layer 3
Call Log
CID/CWCID
Dial Plan
DTMF Mode: Inband, outband and SIP Info
